Add a passive scalar transport model

Extend incompressibleFluid with a new physics model — without modifying the solver itself. The model adds a passive scalar s (dye, tracer, smoke marker) advected by the existing velocity field and diffusing with a configurable coefficient:

\[\frac{\partial s}{\partial t} + \nabla \cdot (U\, s) - \nabla \cdot (D \nabla s) = 0\]

You should be comfortable with type hints and decorators. If you haven’t run a NeoFOAM case yet, do Run your first NeoFOAM case first.

Plugin imports

import contextlib
import subprocess
from pathlib import Path
from typing import Any

import pybFoam as pyf
import pyvista as pv
from pybFoam import (
    fvm,
    fvScalarMatrix,
    surfaceScalarField,
    volScalarField,
)

from neofoam import FieldUpdates, Model, field

# from neofoam.foam import fvSchemes, fvSolution
from neofoam.io import BaseConfig
from neofoam.solver.incompressibleFluid import run as run_incompressible
from neofoam.solver.incompressibleFluid.models import incompressibleFluidModel
from neofoam.tutorial import clone_case

Scaffold the plugin

register_with adds the empty spec to incompressibleFluid’s plugin registry. The four decorators below populate it.

class PassiveScalarConfig(BaseConfig):
    D: float = 0.0  # diffusivity, m²/s


passive_scalar = Model("passive_scalar").register_with(incompressibleFluidModel)

Activate when constant/scalarProperties is present

Without that file the framework skips the model entirely — no config load, no operations, no overhead.

# Framework note: in the current branch ``@spec.detect`` takes no
# arguments (the old ``case_dir`` parameter was removed) and ``load``
# now receives ``(case_dir, instance_id)`` instead of ``(case_dir,
# entry)``. Detection happens with the case as the cwd, so a relative
# path probes the right file.
@passive_scalar.detect
def detect() -> bool:
    return Path("constant/scalarProperties").exists()

Load the diffusivity from the case

@passive_scalar.load
def load(_case_dir: Path, _instance_id: str) -> PassiveScalarConfig:
    props = pyf.dictionary.read("constant/scalarProperties")
    return PassiveScalarConfig(D=props.get[float]("D"))

Register the new field

The framework topologically sorts every model’s contributions plus the solver’s own. cfg is auto-injected by type — the framework finds the PassiveScalarConfig on runtime.config.

@passive_scalar.build
def build(cfg: PassiveScalarConfig) -> list[Any]:
    def create_s(context: dict[str, Any]) -> volScalarField:
        return volScalarField.read_field(context["mesh"], "s")

    return [field("s", create_s, depends_on=["mesh"])]

Add the transport operation

depends_on=["continuity"] anchors after the pressure-velocity algorithm produces a divergence-free phi — solving with the corrected flux is what keeps the scalar conservative. @fvSchemes.add / @fvSolution.add declare requirements the framework’s verifier checks at startup.

@passive_scalar.operation(depends_on=["continuity"])
# @fvSchemes.add(
#     ddt="ddt(s)",
#     div="div(phi,s)",
#     laplacian="laplacian(D,s)",
# )
# @fvSolution.add("s")
def solve_s(
    self: Any,
    s: volScalarField,
    phi: surfaceScalarField,
) -> FieldUpdates:
    cfg: PassiveScalarConfig = self.config
    D = pyf.dimensionedScalar("D", pyf.dimViscosity, cfg.D)
    sEqn = fvScalarMatrix(fvm.ddt(s) + fvm.div(phi, s) - fvm.laplacian(D, s))
    sEqn.solve()
    return FieldUpdates({"s": s})

Run incompressibleFluid on the bundled case

tutorials/passive_scalar_pitzDaily is pitzDaily plus constant/scalarProperties, 0.orig/s, and matching s entries in the schemes/solution files. The bundled case sets the inlet BC to fixedValue 1 and the internal field to 0 so a clear advection-diffusion front develops. We truncate the runtime so the figure captures the dye plume mid-flight rather than a domain that has equilibrated to s ≈ 1 everywhere.

case = clone_case("passive_scalar_pitzDaily")
(case / "passive_scalar_pitzDaily.foam").touch()
subprocess.run(["blockMesh", "-case", str(case)], check=True)

control_dict = pyf.dictionary.read(str(case / "system" / "controlDict"))
control_dict.set("endTime", 0.05)
control_dict.write(str(case / "system" / "controlDict"))

with contextlib.chdir(case):
    run_incompressible(["neofoam"])

Plot the dye field

reader = pv.OpenFOAMReader(str(case / "passive_scalar_pitzDaily.foam"))

pl = pv.Plotter(off_screen=True, window_size=(900, 360))
pl.open_gif(str(case / "passive_scalar.gif"), fps=10)

reader.set_active_time_value(reader.time_values[0])
mesh = reader.read()["internalMesh"]
pl.add_mesh(
    mesh,
    scalars="s",
    cmap="magma",
    clim=[0, 1],
    scalar_bar_args={"title": "s [-]"},
)
pl.view_xy()
pl.camera.zoom(1.2)

for t in reader.time_values:
    reader.set_active_time_value(t)
    mesh.copy_from(reader.read()["internalMesh"])
    pl.write_frame()

pl.show()
